Views: 0 Author: Site Editor Publish Time: 2025-12-12 Origin: Site
Novices using SC cylinders are prone to malfunctions due to improper matching and neglect of maintenance. Suggestions for entry-level selection and matching: Priority should be given to the combination of CA single ear base and Y-shaped floating joint, which is easy to operate and has wide adaptability. The cylinder diameter should be calculated based on 1.2 times the load, with a safety margin reserved; The air source treatment needs to be equipped with a water separation filter and an oil mist filter, with a medium filtration accuracy of ≥ 40 μ m, to ensure the cleanliness of the cylinder interior.
Daily maintenance focus: Check the air source pressure and oil level of the oil mist device before starting up every day, clean the cylinder surface and piston rod every week, drain condensed water and tighten bolts every month, and add lubricating grease to the oil-free cylinder every 6 months. Novices need to avoid two common misconceptions: one is to ignore buffer adjustment. When starting up, the buffer should be adjusted to the minimum and gradually relaxed to prevent impact damage; Secondly, if it is left unused for a long time without maintenance, it is necessary to install a dust cap and do a good job of rust prevention if it is not used for more than one month.
Simple repair technique: When there is a slight leak, tighten the joint bolts first; If there are scratches on the piston rod, gently polish it with fine sandpaper and apply anti rust oil; If the action is stuck, first check if the pipeline is blocked, clean the filter, and then conduct a no-load test run. If the fault cannot be resolved, it is recommended to contact professionals to avoid blind disassembly and secondary damage.
